First time using this tool? Watch the short tutorial video available in the Help menu.

Settings

Units
Point Spacing X ft
Point Spacing Z ft

Surface

Width  [X]*   ft
Height [Z]*   ft
Base   [Z]   ft

Criteria

Setback*   ft
Average fc
Minimum fc
Ave / Min
Max / Min

Constraints

Quantity
On Center Spacing ft

Target Area

Width [X] ft
Height [Z] ft
Center Offset X ft
Center Offset Z ft

Spacing Results  --

Spacing --   ft
Quantity --
Tilt --

Calculation Results  --

Minimum --  fc
Average --  fc
Maximum --  fc
Ave / Min --
Max / Min --
Point Spacing --  ft
Fixture to Surface Eff. --
Lamp to Surface Eff. --
iterations --
Points Calculated --

Display

Points
--
  fc
fc
fc
fc
Project Information
Project Name Your Name
Project Description Company Name
Your Phone
Your Email
Click the '+ tab' to select a product
Visual design tools allow you to open and save projects to your Dropbox account. Would you like to log in now?"
Customers enter your email and password.
Agents and ABL Employees enter your Agile username and password.

The Visual Floodlight / Wallwash tool was developed to help specifiers select flood, sign, and wall lighting products. The tool only considers the direct illumination component's effect on the wall. There are no other surfaces in the calculation that may exist and affect actual results in installations. Please use Visual 2012 to perform detailed analysis for your lighting design.

If you specify a tilt angle and illuminance criteria the tool will attempt to find an on center spacing that meets your criteria. It is possible for there to be no on center spacing that can meet your criteria at the specified setback and tilt. You may also leave the tilt field blank (not zero) and allow the tool to determine an optimum tilt for your criteria. The optimum tilt will change depending on which criteria you enter. It is possible that no tilt angle can meet all your criteria, in this case an aiming point 2/3 up the wall will be returned.

You may also constrain your design to a specific on center spacing or quantity. If you enter a value in both constraints the tool will not attempt to optimize based on any illuminance criteria, instead it will return your specified design.

For guidelines on flood lighting refer to the Facade Lighting Guide or the Sign Lighting Guide

If you have any questions not answered by the tutorial video or comments on this tool, email support@visual-3D.com.
